Kicker IQ500.1 Q-Class Amplifier
- 8.05 LBS
- Calculated at Checkout
Kicker Q-Class IQ500.1 500 RMS Subwoofer Amplifier
IQ Amplifiers combine the two most import things for great sound: power and control. With a massive Class D power plant and the included TWEEQ™ tuning software, your music can achieve the realism and raw power you crave.
The soundstage is yours to command. The revolutionary TWEEQ™ tuning software is included with every Kicker IQ amp, built to make crafting audio to your exact standards as easy as clicking a mouse or touching a tablet.
Designed entirely in the USA, KICKER delivers the ultimate in sound quality and power by hand-selecting the finest components. Paired with an extremely efficient Class D power supply, IQ Amplifiers give you the nuance and thunder with equal ease.
The included IQRC remote easily controls your amp volume, bass boost and more with a single cable connection. The optional IQI Bluetooth Interface lets you play Bluetooth audio, answer phone calls and use the TWEEQ software to control as many as four IQ amps, all from your phone or tablet.
All IQ amplifiers come with the revolutionary TWEEQ tuning software. Available as a free app for PC, iOS and Android, this tuning system allows you the freedom to dial in your perfect sound – without buying or installing a separate processor.
Equipped with a simple walk-through configuration process, TWEEQ includes every tool you need to craft a truly excellent sonic environment. A graphic speaker selection menu, +/- 12dB equalizer with 31-bands, adjustable 24dB crossover and time alignment is all included for every channel of the amp. Access the Advanced settings for time delay controls, phase options, a full limiter/compressor, and input mixer to make your sound stage as unique as you are.
Want to TWEEQ your system wirelessly? Simply add the IQI Intelligent Interface and control as many as four IQ amplifiers with Bluetooth®! TWEEQ™
The IQ500.1 Mono Amplifier delivers power in a sophisticated yet simplistic design.
Best described as “cutting-edge” yet remarkably easy to use, the amplifier includes a highly configurable digital signal processor called TWEEQ. Using the included USB cable, your PC instantly becomes a powerful graphic interface for unrivaled acoustic control.
The IQ500.1 delivers 250 watts at 4Ω and 500 watts at 2Ω. See below for more details.
|RMS Power [Watts]||@ 14.4V, 4Ω mono, ≤ 1% THD+N : 250 x 1
@ 14.4V, 2Ω mono, ≤ 1% THD+N : 500 x 1
|Length [in, cm]||9-7/16, 24|
|Height [in, cm]||2-1/16, 5.2|
|Width [in, cm]||7-9/16, 19.1|
|Frequency Response [Hz]||25 - 180|
|Signal-to-Noise Ratio [dB]||>95, A-weighted, re: rated power|
|Input Sensitivity||Low Level: 125mV-5V
High Level: 250mV-10V
|Selectable Electronic Crossover||Variable LP 40-180Hz, 24dB/octave|
|KickEQ™ Bass Boost (end panel adjustable)||Variable 0–18dB @ 40Hz|
|"KickEQ+™ Parametric Bass Boost(Remote Control Adjustable)"||Boost : Variable 0-18db
Adjustable Center Frequency : 24Hz-80Hz
Bandwidth : .5-10
|Subsonic Filter||25Hz, 24dB/octave|
|CEA Power||250 x 1 @ 4 ohms, 14.4VDC, 1% THD, CEA-2006B (Watts)|
|CEA Signal-to-Noise Ratio||-80dB CEA-2006B (ref: 1W, A-weighted)|
Kicker TWEEQ Control
|Selectable Active Crossover||Variable High Pass 10-100Hz, Variable Low Pass : 40-200Hz
Ajustable Butterworth slope : OFF, 6, 12, 18 or 24dB/Octave
Adjustable Linkwitz-Riley slope : OFF, 6 or 12dB/Octave
|KickEQ™||Graphic 31 Band, 1/3 octave, + or - 12dB|
|Time Delay||Adjustable Delay : 0-20ms
Adjustable increments : .02ms, .1 ms and 1.0 ms
|Compressor||Adjustable Attack and Release time; Adjustable 1:1 - 10:1 ratio
Adjustable Threshold, -80 - 10dB
|Input Mixer||Maps signal inputs to specified speaker outputs|
Manufacture SKU #:
Number Of Channels:
RMS Power In Watts:
