Description
MB Quart compact Two Channel, 400 watt Powersports amplifier with on-board equalization and simple installation with quick release connectors.
Specifications
CLASS
Full Range Class D
VARIABLE VOLTAGE
0.2V~9V
SIGNAL TO NOISE RATIO
>90dB
FREQUENCY RESPONSE
20Hz-20kHz
CROSSOVER TYPE
N/A
CROSSOVER FREQUENCY RANGE
CH1 & CH2
Switched HP/ Full
CROSSOVER FREQUENCY RANGE
CH3 & CH4
Switched HP/ Full
BASS BOOST
0-12dB@45Hz
SUBSONIC FILTER
N/A
POWER @ 2-OHMS
4 x 80W
POWER @ 4-OHMS
4 x 40W
TOTAL CHANNELS
4
AUDIO INPUTS
RCA
POWER TERMINAL 12V/GND
Molex 10 ga
SPEAKER TERMINAL WIRE GAUGE
Molex Plug Connector
FUSING
1 x 30 Amps
CERTIFICATIONS
Marine & Powersports
DIMENSIONS
3.70 X 5.51 X 1.77 in
9.4 X 14.0 X 4.5 cm
WEIGHT
2.16 lbs (0.98 kg)
