Description
Included in this kit
This bundle includes a Cicada Audio CXX65.4 - Pro Coaxial Speakers 6.5-inch- 4 Ohm, Pair, a Cicada Audio CX250.2D - 2 X 250 @ 2 Ohm Amplifier, a Cicada Audio HDPG8K - 8 Gauge Power/Ground Kit, a Cicada Audio HDLOC-MAX2 - High Output 2-Channel Line Output Converter, and a Cicada Audio HDFoM - H-D Output Molex -FRONT.
1x Cicada Audio CXX65.4 - Pro Coaxial Speakers 6.5-inch- 4 Ohm, Pair - (CXX65.4)
Features:
Designed for 2014 + H-D® factory designed locations
V8™ Dispersion Guide
Exclusive Cicada Design for 360o sound from tweeter
Rain or Shine™ all weather performance design
Built-In 6dB crossover
PEI tweeter dome for best sound dispersion
Moisture resistant
Brighter sound
More efficiency
Kevlar cone
Extremely lightweight and strong
Moisture resistant
Maximized efficiency
Copper wire voice coils offer great sound while generating less heat
N45H Neo Magnets
High temperature resistant Polycarbonate custom tooled basket
UV protection over all surfaces
5-inch Grills and Hardware are included
Two (2) year warranty
Specification:
4Ω / 6.5-inch high performance coaxial driver
Power handling: 100W RMS/200W MAX
Voice Coils: 1.4-inch/35mm mid-bass and 1-inch/25mm Tweeter
Cone: Kevlar
Tweeter Dome: PEI
Magnet: Neodymium
Sensitivity: 93dB
Frequency response 55 Hz – 20 kHz +/- 3dB
Mounting Depth: 2.26-inch/57mm
Mounting Diameter: 5.43-inch/138mm
1x Cicada Audio CX250.2D - 2 X 250 @ 2 Ohm Amplifier - (CX250.2D)
POWER SUPPLY
Voltage: 8 - 16 VDC
Idling current: 1.32 A
Switched off: <2 mA
Consumption @ 14.4 VDC 2Ω Max Musical Power (without CPL): 30 A
Remote IN 7 ÷ 15 VDC (1 mA)
Fuse 30 A
DC Offset (Senses DC offset for Turn on/off) Hi-Level Input (speaker)
VOX (Signal Sensing Turn on/off) Hi or Lo Level Input (speaker/RCA)
REM (Switched 12V on/off) Switched 12V turns the amplifier on
AMPLIFIER STAGE
Distortion - THD @ 1 kHz, 4 Ω, 90% Output Power: 0.10 %
Bandwidth @ -3 dB, 2 V RMS, 4Ω: 10 ÷ 20k Hz
S/N ratio @ A weighted, 2V, Output Power: 91 dBA
Damping factor @ 1 kHz, 2 V RMS, 4Ω: >200
Input sensitivity: 1 - 15 V RMS
Input impedance: 15k Ω
LOAD IMPEDANCE (MIN):
• 2 Ch: 1-2 2Ω
• 1 Ch: Bridge (1-2) 4Ω
MAX POWER 500 W
OUTPUT POWER (RMS) @ 12.5 VDC, 1% THD:
• 2 Ch @ 4Ω: 132 W x 2
• 2 Ch @ 2Ω: 218 W x 2
• 1 Ch - (Bridge 1/2) @ 4Ω: 435 W x 2
OUTPUT POWER (RMS) @ 14.4 VDC, 10% THD:
• 2 Ch @ 4Ω: 150 W x 2
• 2 Ch @ 2Ω: 250 W x 2
• 1 Ch - (Bridge 1/2) @ 4Ω: 500 W x 1
SIGNAL CONNECTIONS
Input Stage: 2 channels in Both High and Low Input
Input Voltage Range: 0.2 Vac - 15Vac
CEA SPECIFICATIONS
Output power @ 4Ω, ⩽1% THD+N, 14.4 V: 150 W x 2
SN ratio (ref. 1 W output): 75 dBA
POWER OUTPUT STEREO / 4 CHANNEL
• 2 X 150 WRMS into 4 ohms @ 14.4 Vdc
• 2 X 250 WRMS into 2 ohms @ 14.4 Vdc
BRIDGED MONO - 1 CHANNEL
• 1 X 500 WRMS into 4 ohms @ 14.4 Vdc
• Frequency Response - 20-20,000 +/- 3dB THD < 0.5%
• THD + N (10% Rated Power): 0.1%
• Product Dimensions (Inches / Millimeters): 7.6 x 4.0 x 1.4 in / 193 x 103 x 36 mm
• Weight (kg/lb): 1.36 / 2.99
1x Cicada Audio HDPG8K - 8 Gauge Power/Ground Kit - (HDPG8K)
HD 8 Gauge Power Harness Kit
1x Cicada Audio HDLOC-MAX2 - High Output 2-Channel Line Output Converter - (HDLOC-MAX2)
High output line level converter for 2014 and newer H-D® radios. Includes H-D® Molex® connectors. Selectable load 20k at 60Ω or 20Ω. Three ways to turn-on – VOX / REM / DC offset. Remote out delay of 4 / 10 / or 20 seconds. 10 volts out maximum.
1x Cicada Audio HDFoM - H-D Output Molex -FRONT - (HDFoM)
HDFoM FRONT HD SPEAKER TO CICADA AMPLIFIER INPUT MOLEX
