Description
Included in this kit
Bundles includes: 2 Memphis Audio 15-PRX10D4W 10" dual 4-ohm voice coil subwoofer, Bbox E10D Pro-Series 10” Dual Sealed / Subwoofer Enclosure
Memphis Audio 15-PRX10D4W 10" dual 4-ohm voice coil subwoofer
Specifications: Size (in): 10
Impedance (Ohms): 2 (Dual 4 Ohm)
Resonant Frequency (Hz): 38
Vas (Cf.): 0.728
Moving Mass (Grams): 127.9
Linear Xmax (in): 0.55
Linear Xmech (in): 0.83
Mechanical Q (Qms): 8.64
Electrical Q (Qes): 0.69
Total Q (Qts): 0.64
Sensitivity @ 1W/1M (db): 84.16
Voice Coil Diameter (in): 2
Motor Strength (T/M): 8.94
Magnet Weight (oz): 60
Recommended RMS Power (Watts): 250
Maximum Peak Power (Watts): 500
Cut-Out Diameter (in): 9.25
Frame Diameter (in): 10.55
Mounting Depth (in): 5.18
Driver Displacement (Cf.): 0.12
Bbox E10D Pro-Series 10” Dual Sealed / Subwoofer Enclosure
Pro Tuned 10” Dual sealed subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
1” High-Grade MDF Front Baffle for Ultimate structural rigidity and no-flex construction.
.85 Cubic Feet Net Volume internal air space per sub is ideal for tight accurate bass reproduction. Divided subwoofer chambers
CNC Miter & Dado design and construction for the ultimate in an airtight precision fit of all parts which ensures a rattle and noise-free environment.
Recessed Side Panels increase structural integrity, eliminates unwanted flex and vibration.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Pneumatic Applied Brad Nails to pull tight and hold the MDF parts during the glue drying process and help assure a no-leak, no-rattle air chamber.
Premium OEM Grade Carpeting for factory look and durability.
