Description
JVC KD-R690S Single din Receiver
CD, USB, Aux, Android USB Playback, variable color illumination
Features
Android™ Music Playback via USB
Simply connect your Android smartphone or tablet to the receiver via USB and enjoy a totally “plug and play” music playback solution. The Android Open Accessory Protocol (AOA2) is supported so absolutely no preparation or set-up is necessary – just plug it in and it’s ready to play audio files stored on your Android device in what’s called “AUDIO MODE”. Or, by installing the free JVC Music Play app* available on Google Play, you’ll be able to access “AUTO MODE” for added functionality including Folder Up & Down, and Search Artist/Album/Song.
Variable-Color Illumination
You can choose illumination colors from one of 49 presets or customize your own color by adjusting the intensity of RGB (Red, Green, and Blue).
Pandora(Android/iPhone)
Listen to Pandora your smartphone with smooth control on the headunit via USB or Bluetooth connection for iPhone, and via Bluetooth for Android devices.
15-Preset EQ including “drvn EQ”
Preset EQ patterns are selectable from 15 types including ”drvn EQ” that is designed to maximize the performance of JVC drvn Series amplifiers and speakers, as well as producing dynamic sound for any speaker.
Technical Specifications
Display
- Display Type
- 2-Line VA LCD Display
- LCD Color
- White
- Key Color
- Variable Color
- Spanish Text Display Compatible
- Yes
- Auto Dimmer
- Yes
- Brightness Control
- Yes
Media Playback
- MP3 Compatible with Tag
- CD / USB
- WMA Compatible with Tag
- CD / USB
- WAV Compatible with Tag
- USB
- FLAC Compatible with Tag
- USB
Android Control
- Android Music Playback (AUDIO MODE and AUTO MODE)
- Yes (AUDIO MODE & AUTO MODE)[1]
iPod/iPhone Control
- iPod/iPhone Music Playback
- Yes
- Pandora Control (Available in countries that support this service.)
- Yes (via USB)
- iHeartRadio Control (Available in countries that support this service.)
- Yes (via USB)
USB
- Position
- Front
- USB Power Supply
- Yes (1A)
- Drive Change Mode for Mass Storage Class
- Yes
Inputs and Outputs
- AUX Input
- 1 (Front)
- Line Output Terminals (Pair)
- 2 Pairs (Front + Rear/Subwoofer Selectable)
- Pre-Output Level
- 2.5V
- Subwoofer Output with Level/Frequency Control
- Yes (Level -8 - +8)
- Subwoofer Output Level
- 2.5V
Tuner
- SiriusXM Ready
- Yes
- Radio Data Broadcast System (RBDS)
- Yes
- Digital Processing Tuner
- Yes
- Preset Stations
- 18FM + 6AM
- Strong Station Memory (for FM)
- Yes
- Radio Timer
- Yes (Once/Daily/Weekly)
- Tuner Preset Memory (for power disconnection)
- Yes
- FM
- Frequency Range
- 87.9 - 107.9MHz (200kHz)
- AM
- Frequency Range
- 530 - 1,700kHz (10kHz)
Audio
- Maximum Power Output
- 50W x 4 / 50W x 2 +Subwoofer (4 ohms) 50W x 1
- Full Bandwidth Power (at less than 1%THD)
- 22W x 4
- MOS-FET Amplifier
- Yes
- Subwoofer Direct Connection (Mono Lch)
- Yes
- EQ
- Yes (3-Band Parametric EQ)
- Preset EQ
- Yes (15-Preset)
- Digital Track Expander
- Yes
- Bass Boost
- Yes
- Loudness Control
- Yes (Off/Low/High)
- High-Pass Filter/Low-Pass Filter
- - /Yes
- drvnEQ
- Yes
General
- Detachable Face Panel
- Yes
- Steering Remote Control Ready
- Yes
- Dimensions (W x H x D)
- Installation Size
- 7-3/16" x 2-1/8" x 6-1/4" (182 x 53 x 159mm)
- Weight
- 2.65 lbs. (1.2kg)
- Unit weight in individual package
- 3.09 lbs. (1.4kg)
