Description
POWER SUPPLY
Voltage: 9 - 16 VDC
Idling current: 1.32 A
Switched off: <1 mA
Consumption @ 14.4 VDC 2Ω Max Musical Power: 51
Remote IN: 7 ÷ 15 VDC (1 mA)
Fuse: 30 A
DC Offset (Senses DC offset for Turn on/off): Speaker input - selectable
VOX (Signal Sensing Turn on/off): Speakers input - selectable
REM (Switched 12V on/off): Switched 12V turns the amplifier on
AMPLIFIER STAGE
Distortion - THD @ 1 kHz, 4 Ω, 90% Output Power: 0.10 %
Bandwidth @ -3 dB, 2 V RMS, 4Ω: 10 ÷ 20k Hz
S/N ratio @ A weighted, 2V, Output Power: 91 dBA
Damping factor @ 1 kHz, 2 V RMS, 4Ω: >200
Input sensitivity: 0.2 - 12 V RMS
Input impedance: 15k Ω
LOAD IMPEDANCE (MIN):
• 4 Ch: 1-2-3-4 2Ω
• 2 Ch: Bridge (1-2) (3-4) 4Ω
MAX POWER 600 W
OUTPUT POWER (RMS) @ 12.5 VDC, 1% THD:
• 4 Ch @ 4Ω: 70 W x 4
• 4 Ch @ 2Ω: 115 W x 4
• 2 Ch - (Bridge 1/2; 3/4) @ 4 W 218 W x 2
OUTPUT POWER (RMS) @ 14.4 VDC, 10% THD:
• 4 Ch @ 4Ω: 92 W x 4
• 4 Ch @ 2Ω: 152 W x 4
• 2 Ch - (Bridge 1/2; 3/4) @ 4 W 302 W x 2
CEA SPECIFICATIONS
Output power @ 4Ω, ⩽1% THD+N, 14.4 V: 70 W x 4
SN ratio (ref. 1 W output): 75 dBA
SIGNAL CONNECTIONS
Input Stage: 6 channels in High and Low Input, 4 channels / 2 Preouts
DIGITAL SIGNAL PROCESSOR
(32 bit Cirrus Logic; Clock speed: 147 MHz)
Crossover: Full / Hi Pass / Lo Pass / Band Pass
Crossover type and slope: Linkwitz @ 12/18/24/48 dB
Crossover Frequency: 68 steps @ 20 ÷ 20k Hz
Phase inversion: 0° / 180°
Digital Input Equalizer: (to correct HD curve) Audio PreSets
Output Equalizer, Parametrics Equalizers: ±12 dB; 10 pole; 20 - 20k Hz
Time Alignment Distance 0 ÷ 510 cm / 0 to 133.9 in.
Time Alignment Delay 340 to 10 ms
Time Alignment Step 0,08 ms; 2,8 cm / 1.1 in.
SYSTEM PRESETS:
Acoustic Preset 6 Harley Davidson Audio Presets/De EQ
