Description
Included in this kit
This bundle includes a JBL MA1000 Subwoofer Marine Amplifier 1000 watts RMS x 1 at 2 ohms, and 2x JBL CLUB-12 - 12" Marine Audio Subwoofer with RGB Lighting, 400W – White/Gray grills included.
1x JBL MA1000 Subwoofer Marine Amplifier 1000 watts RMS x 1 at 2 ohms (MA1000)
The JBL marine A1000 mono subwoofer amplifier delivers 1000-Watts RMS using a Class D amplifier design to ensure high output and minimum current draw. Speaker-level inputs allow this amplifier to integrate into almost any system, even one using your marine’s factory radio. You can use the low-pass filter and variable bass boost to maximize the performance of your subwoofer and enclosure, while a phase switch ensures that the bass will blend well with your full-range speakers.
Technical Specifications:
mono subwoofer marine amplifier
600 watts RMS x 1 at 4 ohms (1000 watts RMS x 1 at 2 ohms) Max power 2000 watts
1900 watts RMSx1 (Two amplifiers)
Class D amp technology
frequency response: 25-320 Hz
variable low-pass filter (32-320 Hz, 12 dB/octave)
variable bass boost (0-12dB at 45Hz)
phase switch (0, 180 degrees)
wired remote level control included
preamp inputs and outputs
speaker-level inputs (speaker wire-to- RCA adapters included)
4-gauge power and ground leads recommended — wiring and hardware not included with amplifier
fuse rating: 35A x 3
WxHxD=320mm x 51.3mm x 180mm/12-5/8” x 2-1/16” x7-1/8”
What’s in the Box
One marine A1000 mono subwoofer marine amplifier
Six 35A ATO fuses (3 installed, 3 spare)
2 Bare wire-to-RCA adapters
Remote bass control module
16.5’ Remote control cable (RJ-25 plugs on both ends)
2 Self-tapping screws for remote (M3 x 15mm)
4 Mounting screws (M4 x 53mm)
Owner’s Manual
Two JBL stickers
1 logo badge
2x JBL CLUB-12 - 12" Marine Audio Subwoofer with RGB Lighting, 400W – White/Gray grills included (CLUB-12)
JBL Club Marine Speakers are ready for your next outdoor adventure. These fully marinized speakers not only deliver JBL sound, they also provide RGB lighting to bring the sound to life. Engineered to withstand sun, salt, sea spray and wash downs, they feature sealed motor structures, UV resistant one-piece cast-polymer baskets, a sealed magnet and rubber surrounds. The polypropylene cone and balanced silk dome tweeter provide great bass, smooth hights and lots of output to ensure every note can be heard loud and clear. With two grille colors included in the box, you easily match your speaker with your boat.
Twist-Lock Speaker Grilles -
JBL Club Marine Speakers have two grille color options in the box (gloss white & satin grey), with a twist-lock design so you can easily match the grille color to your preference during installation. The innovative design hides the mounting fasteners so your installation results in a clean finish with high cosmetic appeal.
Outdoor Performance & Marine Rated -
JBL uses marine-grade materials & components to suit the demands of harsh outdoor environments, with an IPx5 marine rating from front of speaker, and accentuated performance at frequencies heard in open-air environments.
RGB Illuminated Speaker Cones -
Unique and eye-catching RGB illuminated speaker cones are capable of displaying seven colours out of the box, when hard-wired to your vessel lighting, or you can have even more color options when wired to an external lighting controller.
Specifications -
• Club Marine 12" Subwoofer - JBLMARSUBCB122AM
• Power Handling: 400Wrms, 1200W peak
• Sensitivity (@ 2.83V): 89dB
• Frequency Response: 25Hz – 500Hz
• Nominal Impedance: 4ohm
