Description
Included in this kit
This bundle includes a Kenwood KAC-D3104 KENWOOD Class D 4/3/2 HPF/LPF Channel Amplifier, a Kenwood KFC-P710PS 6-1/2" mid-woofer and 1" Swivel Tweeter - Component Speaker System 280W Max Power, and a Kenwood KFC-C5798RS 4" 2-Way Speaker System, 240W Peak Power.
1x Kenwood KAC-D3104 KENWOOD Class D 4/3/2 HPF/LPF Channel Amplifier (KAC-D3104)
D Series Amplifiers provide a powerful solution in a compact design, ideal for upgrading your car audio system.
Expanded Frequency Response
Supporting Hi-Res Audio, KAC-D3104 is ideal for high resolution audio playback as it features a frequency response that extends to 50kHz.
Dual Sigma Drive
This advanced negative feedback circuit improves damping factor and increases accuracy and sound quality. When a signal is passed to a subwoofer, like a 50Hz note, the speaker will move and create the note. However, because the speaker has mass and a suspension, it won't stop moving once it's in motion. This extra movement (sound) creates a type of distortion that's not part of the original signal. The negative feedback circuit senses this unwanted movement and sends out an opposite pulse to stop the speaker like an electronic brake.
Small Size Big Power
The KAC-D3104 is small in size but with its tremendous sound output, it is extremely versatile. It can be installed in vehicles where space is limited and is perfect for vehicle owners who don't want to sacrifice cargo room or who prefer hidden installations.
General Features
MAX POWER: 600W
RMS POWER OUTPUT: (4Ω)50W x 4
RMS POWER OUTPUT: (2Ω)75W x 4
RMS POWER OUTPUT Bridged: 150W x 2 (Bridged)
Features:
Speaker Level Input
Signal Sensing Turn-On
Variable High Pass Filter
Variable Low Pass Filter
Bass Boost
Dimensions: (W)6-11/16” x (H)2-3/16” x (D)7-3/8”
Weight: 2.9 lbs (1.3kg)
1x Kenwood KFC-P710PS 6-1/2" mid-woofer and 1" Swivel Tweeter - Component Speaker System 280W Max Power (KFC-P710PS)
Kenwood's KFC-P710PS 6-1/2" component system provides a rich, dynamic sound reinforced by a solid low end. This polypropylene woofer cone sports a Diamond Array pattern that increases surface strength for reduced distortion and improved bass response. A rubber surround provides reliable playback in spite of the prolonged exposure to the elements that life in your car doors brings.
Features -
• Sensitivity: 86 dB / W / m
• Frequency Response: 63 Hz - 24k Hz
• Cutout Diameter: 4-15/16inch
• Mounting Depth: 2-3/16inch
• Gross Weight: 2.30lbs
• Weight of Magnet (Woofer): 0.72lbs
Tweeter -
• Width: 37.5mm 1-1/2in
• Height: 37.5mm 1-1/2in
• Depth: 19.1mm 3/4in
Accessory -
• Grille: *2
• Grille Holder: *2
• In-Line Network: *2
• Tw Bracket
• Free Mount: *2
• Flush Mount: *2
• GM Bracket: *2
• Screw Set
• φ4*25: *8
• φ4*6: *8
• φ3*16: *4
• Speed Nut
• φ4: *8
• φ3: *4
• Wing Nut M5: *2
• Butyl Rubber: *1
1x Kenwood KFC-C5798RS 4" 2-Way Speaker System, 240W Peak Power (KFC-C5798RS)
Diamond Array Pattern Woofer Cone
Enhances sound and reduces distortion.
Acoustic Sound Harmonizer
Produces a smooth and natural sound by controlling woofer sound waves and allowing only certain frequencies to pass through the holes of the tweeter panel.
Sound Field Enhancer
This unique shape of the tweeter creates strong frontward sound as well as a wider sound field in 5kHz and higher frequencies.
Factory Location Fit
The tweeter height is designed as low as possible, allowing the speakers to easily fit in most factory locations.
Black Painted Yoke and Plate
By implementing black paint on these parts, heat is released efficiently inside the magnetic circuit, resulting in temperature reduction of the voice coil and improved durability.
Optimized Woofer Damper Shape
Stress leveling points increase durability and provide a smoother sound response.
General Features
Peak Input Power: 320W
RMS Power: 80W
Sensitivity: 88 dB/ W / m
Frequency Response: 69Hz -20kHz
Impedance: 4Ω
Woofer Features: 5 x 7 inch Polypropylene Cone
Tweeter Features: 1-3/16 inch Balanced Dome
Cutout Diameter: 4-7/8 x 7-3/16 inch
Tweeter Height: 5/16 inch
Mounting Depth: 2-1/16 inch
